Fine Rock Breaker
Fine Rock Breaker is one of India’s largest selling hydraulic rock breaker brand. It has carved a niche for itself as the highest value for money in the rock breaker market. We offer rock breakers as per the choice and need of hirers as well as contractors.
FEATURES:
Auto Stop Valve
Anti Blank Fire
Rigid Accumulator
Hardox Plate
Proper Weight
High Output – High Profits
High Strength And Durability – Low Maintenance
High Reliability – Faster Project Completion
More Fuel Efficient – Save Money
FINE 3X
Opening Weight: 144 kg
Overall Height(with bracket): 1271 kg
Operating Pressure: 80 - 110 bar
Required Oil Flow: 20 - 30 lpm
Impact Rate: 600 - 1000 bpm
Tool Diameter: 45 mm
Suitable Base Machine: 1.3 - 4 ton
FINE 6X
Opening Weight: 405 kg
Overall Height(with bracket): 1870 kg
Operating Pressure: 90 - 130 bar
Required Oil Flow: 45 - 90 lpm
Impact Rate: 400 - 800 bpm
Tool Diameter: 72 mm
Suitable Base Machine: 5 - 8 ton
FINE 12X
Opening Weight: 900 kg
Overall Height(with bracket): 2400 kg
Operating Pressure: 150 - 180 bar
Required Oil Flow: 90 - 120 lpm
Impact Rate: 600 - 400 - 900 bpm
Tool Diameter: 110 mm
Suitable Base Machine: 10 - 14 ton
FINE 23X Plus
Opening Weight: 1760 kg
Overall Height(with bracket): 2707 kg
Operating Pressure: 160 - 180 bar
Required Oil Flow: 120 - 180 lpm
Impact Rate: 350 - 550 bpm
Tool Diameter: 140 mm
Suitable Base Machine: 18 - 28 ton
FINE 37X
Opening Weight: 2350 kg
Overall Height(with bracket): 3100 kg
Operating Pressure: 160 - 180 bar
Required Oil Flow: 180 - 220 lpm
Impact Rate: 300 - 500 bpm
Tool Diameter: 155 mm
Suitable Base Machine: 30 - 38 ton
FINE 46X
Opening Weight: 3314 kg
Overall Height(with bracket): 3612 kg
Operating Pressure: 160 - 180 bar
Required Oil Flow: 180 - 220 lpm
Impact Rate: 300 - 500 bpm
Tool Diameter: 155 mm
Suitable Base Machine: 30 - 38 ton
FINE 65X
Opening Weight: 4100 kg
Overall Height(with bracket): 3775 kg
Operating Pressure: 150 - 180 bar
Required Oil Flow: 250 - 350 lpm
Impact Rate: 600 - 200 - 400 bpm
Tool Diameter: 180 mm
Suitable Base Machine: 50 - 65 ton
FINE 80X
Opening Weight: 6300 kg
Overall Height(with bracket): 4200 kg
Operating Pressure: 180 - 210 bar
Required Oil Flow: 300 - 400 lpm
Impact Rate: 180 - 350 bpm
Tool Diameter: 200 mm
Suitable Base Machine: 65 - 85 ton
NOTE: Due to constant product upgradation specifications are subject to change without prior notice.
